HD Digital LED Poster

Features Specifications Applications Product Documents FAQs

Features

	01. Ultra Slim & Light Weight Digital LED Poster Custom made & slim aluminum frame and high precision cabinet design Only 1mm for ultra slim frame and 2mm bezel for connecting together, which is almost invisible with good contents LED poster display is easy transport with wheels on bottom The LED poster is also light weight design with 30kg per piece
02. Plug & Play Digital LED Poster Signage Plug & Play Solution via USB, the LED poster can automatically play video, pictures, text, and other programs once you connect the plug without repeating software settings and other work. Simple setting, unique design, and user-friendly software, LED poster is an LED display product that is very suitable for end-users to use.
	03. Single & Multiple Units for Digital LED Poster LED poster display can work individually for a single screen or together for a bigger led screen High refresh rate and perfect visual performance Built-in video processor for led poster display 6pcs for a 16:9 golden ratio screen 10pcs for a HD 1080P screen
04. P2/P2.5 Higher Resolution LED Poster Display P3 smart LED poster is the best-seller model It's enough for regular events and applications P2/P2.5 LED poster is much higher resolution and clarity It's better for high-end markets and applications
	05. Digital LED Poster with Multiple Control Solutions LED poster display supports HDMI/LAN/WiFi/USB Control With built-in synchronous and asynchronous controller, the LED poster can be living streaming for events, or advertising media player without PC Supports Windows system PC & mobile App(IOS/Android) 4G module controller for remote control(Optional) Audio/light sensor is also available for more intelligent control
06. Flexible Installation for Digital LED Poster Creative led poster display supports multiple installations Freestanding: no need extra structure, more easier and simpler Hanging: from the ceiling for shop window advertising Wall-mounted: perfect for indoor advertising applications Horizontal applications: wider viewing angle
	07. LED Poster Display for Creative Splicing The digital LED poster supports flexible and creative splicing, such as vertical, horizontal, special and unique design It also can be custom made solution according to your project
08. Broad Applications for LED Poster Display Digital LED poster is perfect for retail, events, trade shows, exhibitions, conferences, stages, concerts and etc, such as shopping malls, shop window, restaurants, airports, stations, museums, cinemas, showrooms, bars, conference rooms. The LED poster is more popular and attracting with digital advertising than traditional roll-up. It can increase your sales for 35%-50% with more potential customers
	09. Better Protection for Packing The LED poster display has flight case and strong honeybox case for packing. It both can protect digital LED poster well for delivery. Flight case is better if you want them frequent transport for events, trade shows, exhibitions, and rental business. Strong honeybox case is ok if it's for your own use and no need for frequent transport.
10. Integrated Software & Hardware Solution No matter for hardware, and also for software, our led banner both supplies integrated solutions. Each led banner display has own media player for individual use and multiple units applications. When working together for a big screen, there's no need for extra video processor. With such design, it not only can save cost and time, but also it's much easier and user-friendly for customers. For integrated hadrware design and solution, we make it as light as 28kg only.

Specifications

Model Type	DP2	DP2.5	DP3
Pixel Pitch	2mm	2.5mm	3mm
LED Type	SMD1515	SMD2020	SMD2020
Pixel Type	1R1G1B	1R1G1B	1R1G1B
Module Size	320×160mm	160×160mm	192×192mm
Module Pixel	160×80 Pixel	64×64 Pixel	64×64 Pixel
Module Size	640×1920mm	640×1920mm	576×1920mm
Screen Resolution	320×960 Pixel	256×768 Pixel	192×640 Pixel
Viewing Distance	≥2m	≥2m	≥2m
Brightness	800 cd/m²	1,000 cd/m²	1,000 cd/m²
Viewing Angle	120° (H)/120°(V)	120° (H)/120°(V)	120° (H)/120°(V)
Weight	32kg	32kg	28kg
Case Material	Aluminum	Aluminum	Aluminum
Grayscale	16 bits	16 bits	16 bits
Video Frame Rate	60 Hz	60 Hz	60 Hz
Refresh Rate	≥3,840Hz	≥3840Hz	≥1,920Hz
Drive Mode	1/40 Scan	1/32 Scan	1/32 Scan
Input Voltage	AC90-240V	AC90-240V	AC90-240V
Life Span	≥ 100,000 Hours	≥ 100,000 Hours	≥ 100,000 Hours
MTBF	≥ 10,000 Hours	≥ 10,000 Hours	≥ 10,000 Hours
Application	Indoor/Semi-Outdoor	Indoor/Semi-Outdoor	Indoor/Semi-Outdoor
Control Method	HDMI/LAN/WiFi/USB	HDMI/LAN/WiFi/USB	HDMI/LAN/WiFi/USB
Temperature Operating (℃)	.-40°～+75°	.-40°～+75°	.-40°～+75°
Working Humidity	10%–95%RH	10%–95%RH	10%–95%RH
Power Protection	Over-current/Over-voltage protection	Over-current/Over-voltage protection	Over-current/Over-voltage protection

Applications

No matter for commercial such as shopping malls, airports, stations, supermarket, hotels or rental such as performances, competitions, events, exhibitions, celebrations, stage, HSC Led can provide best digital led poster for you. Some clients buy LED poster for own use, and most of them do LED poster rental business. The following are some digital LED poster cases from our clients.

Window LED Poster Display-4 (1) led poster screen led poster-53 (2)

Product Documents

DP3 LED Poster-HSC LED.pdf

FAQs

Q: What advantages of digital LED Poster compare to Common LED Display?

A: Both LED poster displays and LED screen displays are excellent digital tools to advertisement and promote your brand and messages. But LED Poster displays has more unique avantantages and features.
Easy moving: Led poster displays can be easily moved in any location without needing any tools or equipment. Moreover, you can also adjust and set the working time of these screens, making sure when it needs pause and when it should run – without keeping your eyes on it.
Easy operation: you just need to press a single button and easily operate your poster display without any technical issues. Moreover, LED posters allow multiple installation methods to meet your every advertising and event display needs.
Multiple Media Option: Led poster display has multiple media options such as graphics, videos, and other vivid creativity options; all available in the setup options of a poster screen.

Q: Is an LED poster display cheaper than a regular LED display?

A: Yes, digital LED poster price is generally cheaper than other LED displays. There are some factors that highly determine the pricing of a poster display screen including specifications, Raw materials and core technologies and The enterprise production costs. However, if you are looking for a great digital advertising option for your business or brand promotion with limit budget, LED posters are a good choice for you.

Q: How big are LED posters?

A: The standard size for an LED poster is 640mm (width) and 1920mm (height). And we also provide led poster of 768×1920mm and 576×1920mm size. If you want different size, we offer customization according to the user’s preferences including sizes and colors.
